Texas Instruments’ PGA460 Ultrasonic Processor and Driver for Wide Distance Object Detection, Now at Mouser

Texas Instruments’ PGA460 Ultrasonic Processor and Driver for Wide Distance Object Detection, Now at Mouser



July 28, 2017Mouser Electronics, Inc., the industry’s leading New Product Introduction (NPI) distributor with the widest selection of semiconductors and electronic components, is now stocking the PGA460 and PGA460-Q1 ultrasonic signal processors and drivers from Texas Instruments (TI). Available in both automotive (PGA460-Q1) and non-automotive (PGA460) options, these devices are ultrasonic sensors that support wide-distance object detection at low power, making them well suited to address a broad range of ultrasonic position sensing and robotics applications.

The TI PGA460 and PGA460-Q1 devices, available from Mouser Electronics, are highly integrated system-on-chip (SoC) ultrasonic transducer drivers and a signal conditioners with an advanced DSP core. The devices feature two driver-based topologies: a transformer-based topology that uses a complimentary low-side driver pair that can drive a transducer using a step-up transformer, or a direct-drive topology that utilizes external high-side FETs.



For object detection, the devices employ an echo signal, which reliably detects at distances as low as 5cm and as high as 11m. This functionality is possible through the devices’ analog front-end (AFE), consisting of a low-noise amplifier followed by a programmable time-varying gain stage feeding into an analog-to-digital converter (ADC). This digitized signal is then processed in the DSP core for both near-field and far-field object detection using time-varying thresholds.



Communication interfaces include a time-command interface (TCI), a one-wire USART asynchronous interface and a CMOS-level USART. The devices also feature on-chip system diagnostics, which provide information such as transducer voltage, frequency and decay time. TI PGA460 devices are supported by the BOOSTXL-PGA460 evaluation module, which works with a TI MSP430 USB LaunchPad evaluation kit to create a USB-to-PC graphical user interface (GUI) communication bridge.



To learn more about the PGA460 and PGA460-Q1 devices and the BOOSTXL-PGA460 evaluation module, visit http://www.mouser.com/new/Texas-Instruments/ti-pga460-processor-driver/.



Mouser / Texas Instruments PGA460/PGA460-Q1 Ultrasonic Processor and Drivers

Page Two



With its broad product line and unsurpassed customer service, Mouser strives to empower innovation among design engineers and buyers by delivering advanced technologies. Mouser stocks the world’s widest selection of the latest semiconductors and electronic components for the newest design projects. Mouser Electronics’ website is continually updated and offers advanced search methods to help customers quickly locate inventory. Mouser.com also houses data sheets, supplier-specific reference designs, application notes, technical design information, and engineering tools.



About Mouser Electronics

Mouser Electronics, a Berkshire Hathaway company, is an award-winning, authorized semiconductor and electronic component distributor focused on rapid New Product Introductions from its manufacturing partners for electronic design engineers and buyers. The global distributor’s website, Mouser.com, is available in multiple languages and currencies and features more than 4 million products from over 600 manufacturers. Mouser offers 22 support locations around the world to provide best-in-class customer service and ships globally to over 550,000 customers in 170 countries from its 750,000 sq. ft. state-of-the-art facility south of Dallas, Texas. For more information, visit http://www.mouser.com.



Trademarks

Mouser and Mouser Electronics are registered trademarks of Mouser Electronics, Inc. All other products, logos, and company names mentioned herein may be trademarks of their respective owners.



– 30 –
