Rohde & Schwarz Danmark A/S

VNA Fundamentals & Applications Seminar June 2022

You´re invited!

Join our free seminar VNA Fundamentals & Applications

In the first part of the seminar, we will focus on the fundamentals around a Vector Network Analyzer. We start with the Transmission Line theory and then we go thru the VNA hardware concept and the way the VNA presents S-parameter measurement results. Finally, we will go thru the all-important user calibration of the VNA, why it is necessary and the different calibration methods.

  • Transmission Line fundamentals
  • VNA Hardware concept
  • S-parameters and result presentation
  • Calibration techniques



In the second part of this seminar, we will focus on the typical measurements performed with a Vector Network Analyzer. We start with the filter measurements and how to optimize for speed and dynamic range. Then we go thru both low and high-power amplifier measurements and the pitfalls associated with this. Next there will be an introduction to Time-Domain measurements and finally an introduction to Noise Figure measurements performed with an VNA.

  • Filter & Amplifier measurements
  • Time-Domain measurements
  • Noise Figure measurements

During the different topics, live measurements on a VNA will be demonstrated.

Please note, that the seminar will take place in three different locations. Please choose your favorite location and register already now to save your spot.

  1. Seminar – 07.06.2022, 08.00 – 16.00
    Alsion – Den røde mødeboks
    Alsion 2
    6400 Sønderborg

Register here for the seminar in Sønderborg

  1. Seminar – 08.06.2022, 08.00 – 16.00
    Comwell Rebild Bakker
    Rebildvej 36
    9520 Skørping

Register here for the seminar in Skørping

  1. Seminar – 09.06.2022, 08.00 – 16.00
    Glostrup Park Hotel
    Hovedvejen 41
    2600 Glostrup

Register here for the seminar in Glostrup

We look forward to welcoming you!
